22/8 Tswb Cable, unshielded, 22AWG, 8 cores,

22AWG Conductor: 7/0.254mm los yog 14/0.20mm Stranded Bare Copper Wires los yog Copper Clad Al nyob ntawm tej, PVC-FR/ LSOH rwb thaiv tsev thiab Jacket, 100m los yog 200m yas reel, 2-4 reels ib thawv, sequential footage marking.

Kev tsim kho / Khoom siv / txoj kab uas hla:

	Kev tsim kho	Khoom siv & txoj kab uas hla
8 Cores	Inner Conductor	7/0.254mm Stranded liab qab tooj liab los yog CCA xov hlau
	Rwb thaiv tsev	1.2 hli PVC / PVC -FR
	Lub tsho sab nrauv	5.5 hli PVC / LSOH

8 Cores	Inner Conductor	14 * 0.20mm Stranded liab qab tooj liab los yog CCA xov hlau
	Rwb thaiv tsev	1.6 hli PVC / PVC-FR
	Outer Jacket	5.9 hli PVC / LSOH

Tus naj npawb ntawm Core	Xim
1	Dub
2	Liab
3	Dawb
4	Ntsuab
5	Xim av
6	Xiav
7	Txiv kab ntxwv

Daim ntawv thov:

Qhov kom zoo dua ntawm xws li shielded kev ruaj ntseg cables nyob rau hauv cov kev ruaj ntseg systems yog hais tias nws muab ib co kev tiv thaiv los ntawm lub hwj chim zaus thiab xov tooj cua zaus cuam tshuam, thiab txo tus naj npawb ntawm cov tswb cuav raug generated.

Hais txog kev ruaj ntseg Cable:

Kev ruaj ntseg cable yog ib lub tswv yim dav. Muaj ntau ntau hom kev ruaj ntseg cables muaj nyob rau hauv kev ua lag luam, xws li cov kab yeeb yaj kiab, cov kab tswj kev nkag, cov kab hluav taws xob, cov xov tooj, thiab cov kab hauv TV.

Kev ruaj ntseg cables kuj tseem siv tau rau hauv CCTV Security system thiab nws muab faib ua cov kab video, RF kab, shielded thiab unshielded, teeb liab kab, tswj kab thiab lwm yam qauv.

Cov xwm txheej ntawm Kev Ruaj Ntseg Cable hauv Suav teb:

Cov khoom siv hlau thiab cable, uas yog ib qho tseem ceeb ntawm kev sib txuas thiab kev sib kis nruab nrab hauv kev ruaj ntseg, tau txuas ntxiv mus rau kev siv ntau xyoo tom qab xyoo raws li ntau yam kev txhawb nqa kev ruaj ntseg kev lag luam tau hloov kho tsis tu ncua thiab tag nrho kev lag luam tau loj hlob sai.

1(2) 2(1) 3(1)
